COOLER MASTER MWE Gold 1250 V2 ATX 3.1

Specifications :

Model
- MPE-C501-AFCAG-3E**

ATX Version
- ATX Rev. 3.1

PFC
- Active PFC

Input Voltage
- 100-240V

Input Current
- 15-7A

Input Frequency
- 50-60Hz

Dimensions (L x W x H)
- 180 x 150 x 86 mm

Fan Size
- 140mm

Fan Bearing
- Two Ball Bearing

Efficiency
- ≥90% @ Typical Load

80 PLUS Rating
- 80 PLUS Gold

ErP 2014 Lot 3
- Yes

Operating Temperature
- 0-50°C

Power Good Signal
- 100 - 150 ms

Hold Up Time
- ≥16ms at 100% Load

MTBF
- >100,000 Hours

Protections
- OVP / OPP / SCP / OCP / UVP / OTP / Inrush Protection

Regulatory
- TUV, cTUVus, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, BIS

ATX 24 Pin Connectors
- 1

EPS 4+4 Pin Connectors
- 1

EPS 8 Pin Connector
- 1

SATA Connectors
- 12

Peripheral 4 Pin Connectors
- 4

PCI-e 6+2 Pin Connectors
- 3

12V-2x6 Connectors
- 1

Series
- MWE Gold Series

Category
- Above 750W

Modular
- Fully Modular

80 Plus Efficiency
- Gold

Form Factor
- ATX

Watts
- 1250W
