MSI MAG B860M MORTAR WIFI

Name: MSI MAG B860M MORTAR WIFI
Brand: MSi
Price: 4359000.0 IDR
Availability: InStock

Rp 4.359.000

Compare

Brand: MSi

SKU: 824142393895

Estimasi Berat: 3.5 kg

Category: Motherboard

Sub Category: for Intel Processor

Intel B860 Chipset, 4x DDR5 DIMM, Maximum Memory 256GB, Total 3 Slot NVMe, WiFi 7, Bluetooth 5.4, Support Desktop Processors Socket Intel LGA 1851, Micro ATX Form Factor

2 left

Also available at:

Chipset	- INTEL B860
CPU	- Supports Intel Core Ultra Processors (Series 2) - LGA 1851
Memory	- 4x DDR5 UDIMM, Maximum Memory Capacity 256GB - Supports Dual-Controller Dual-Channel mode
Onboard Graphics	- 1x HDMI Support HDMI 2.1 with FRL, maximum resolution of 8K 60Hz/ * - 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz/ * - 1x Type-C DisplayPort Thunderbolt 4 ports, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz*
Slot	- 1x PCI-E x16 slot - 1x PCI-E x4 slot
Audio	- Realtek ALC897 Codec - 7.1-Channel High Definition Audio - Supports S/PDIF output
Storage	- 3x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260/2242 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices - 4x SATA 6G
LAN	- Intel Killer E5000 5Gbps LAN
WIRELESS LAN & BLUETOOTH	- Intel Killer BE1750x Wi-Fi 7 - The Wireless module is pre-installed in the M.2 (Key-E) slot - Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps - Supports 802.11 a/ b/ g/ n/ ac/ ax/ be - Supports Bluetooth 5.4**, MLO, 4KQAM
LED FEATURE	- 4x EZ Debug LED - 1x EZ Memory Detection LED
OPERATING SYSTEM	- Support for Windows 11 64-bit
PCB Info	- mATX - 243.84mmx243.84mm
