ASUS RT-BE92U

Specifications :

Model
- ASUS RT-BE92U

Product Segment
- BE9700 ultimate BE performance : 1032+2882+5764 Mbps

WiFi Data Rate
- WiFi 7 (802.11be) (2.4GHz): up to 1032 Mbps
- WiFi 7 (802.11be) (5GHz): up to 2882 Mbps
- WiFi 7 (802.11be) (6GHz): up to 5764 Mbps

Antenna
- External antenna x 4

Transmit / Receive
- 2.4GHz 3x3
- 5GHz 2x2
- 6GHz 2x2

Processor
- 2.0GHz quad-core processor

Memory
- 256 MB Flash and 1 GB DDR4 RAM

Boosts Speed
- OFDMA (Orthogonal Frequency Division Multiple Access)
- Beamforming: standard-based and universal
- 4096-QAM high data rate
- 20/40/80/160/320 MHz bandwidth

Operating Frequency
- 2.4 GHz
- 5 GHz
- 6 GHz

Operating Mode
- Wireless Router Mode
- AiMesh Node Mode
- Access Point Mode
- Media Bridge Mode
- Repeater Mode

I/O Ports
- 1 x 10Gbps for WAN/LAN
- 1 x 2.5Gbps for WAN/LAN
- 3 x 2.5 Gbps for LAN
- USB 3.2 Gen1 x1

Buttons
- WPS Button, Reset Button, Power Switch

LED Indicator
- Power x1
- WAN x1
- LAN x1
- 2.4GHz x1
- 5GHz x1
- 6GHz x1

Power Supply
- AC Input: 110V~240V(50~60Hz)
- DC Output: 12 V with max. 3 A current

Product Dimensions
- 247.18 x 101.59 x 287.47 mm / 9.73 x 4.00 x 11.32 inch

AiMesh
- Yes

AiProtection
- AiProtection Pro : Yes

VPN
- Instant Guard
- Yes
- VPN Client Open VPN
- VPN Client WireGuard
- VPN Server Open VPN
- VPN Server WireGuard
- VPN Fusion

WAN
Internet Connection Type :
- PPPoE
- PPTP
- L2TP
- Automatic IP
- Static IP
-  IPSec

LAN
- Yes
- Maximum Manually Assign IP Address Rule : 128

Wireless
- MU-MIMO

- Yes
- Maximum MAC Filters : 64
