GIGABYTE B550M DS3H AC R2

CPU
- AMD Socket AM4

Chipset
- AMD B550

Memory
- 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)of system memory
- Dual channel memory architecture

Onboard Graphics
Integrated Graphics Processor with AMD Radeon Graphics support:
- 1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz
* Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.

- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.1 version, HDCP 2.3, and HDR.
- Maximum shared memory of 16 GB

Audio
- Realtek ALC1220 CODEC
* The back panel line out jack supports DSD audio.
- High Definition Audio
- 2/4/5.1/7.1-channel

LAN
- Realtek GbE LAN chip (1 Gbps/100 Gbps/10 Mbps)

Wireless Communication module
Realtek Wi-Fi RTL8821CE
- WIFI 802.11 a, b, g, n, ac, supporting 2.4/5 GHz Dual-Band
- BLUETOOTH 5.0
- Support for 11ac wireless standard

Expansion Slots
- 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
Chipset:
- 1 x PCI Express x16 slot (PCIEX4), supporting PCIe 3.0 and running at x4
- 1 x PCI Express x1 slot (PCIEX1), supporting PCIe 3.0 and running at x1

Storage Interface
- 1 x M.2 connector (M2A_CPU)
- 1 x M.2 connector (M2B_SB),
- 4 x SATA 6Gb/s connectors

Operating System
- Support for Windows 11 64-bit
- Support for Windows 10 64-bit

Form Factor
- Micro ATX Form Factor; 24.4cm x 24.4cm
