GIGABYTE B650M K
Rp 1.899.000
Also available at:
Product description
| Model | B650M K (rev. 1.0) |
|---|---|
| CPU | AMD Socket AM5, support for: AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen™ 9000 Series Processors |
| Chipset | AMD B650 |
| Memory | Support for DDR5 8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800 MT/s memory modules 4 x DDR5 DIMM sockets supporting up to 256 GB Dual channel memory architecture Support for non-ECC Un-buffered DIMM Support for AMD EXPO™ and XMP memory modules |
| Onboard Graphics | Integrated Graphics Processor: 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz (DisplayPort 1.4) 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz (HDMI 2.1) |
| Audio | Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel |
| LAN | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Expansion Slots | CPU: 1 x PCI Express x16 slot (PCIEX16), supports PCIe 4.0 x16/x8/x4 mode (depending on CPU) Chipset: 1 x PCI Express x1 slot (PCIEX1), supports PCIe 3.0 and running at x1 |
| Storage Interface | CPU: 1 x M.2 connector (M2A_CPU), type 2580/2280 (PCIe 4.0 x4/x2 SSDs) 1 x M.2 connector (M2B_CPU), type 25110/22110/2580/2280 (PCIe 4.0 x4/x2 SSDs) 4 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, and RAID 10 for both NVMe SSDs and SATA storage devices |
| USB (Rear Panel) | 1 x USB Type-C® port (USB 3.2 Gen 2) 1 x USB 3.2 Gen 2 Type-A port (red) 2 x USB 3.2 Gen 1 ports 4 x USB 2.0/1.1 ports |
| USB (Internal Headers) | 1 x USB Type-C® header (USB 3.2 Gen 1) 1 x USB 3.2 Gen 1 header (for 2 ports) 1 x USB 2.0/1.1 header (for 2 ports) |
| Internal I/O Connectors | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 1 x addressable LED strip header (D_LED1) 1 x RGB LED strip header 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x Trusted Platform Module header (TPM) 1 x reset jumper 1 x Clear CMOS jumper |
| Back Panel Connectors | 1 x DisplayPort 1 x HDMI port 1 x PS/2 keyboard/mouse port 1 x USB Type-C® port (USB 3.2 Gen 2) 1 x USB 3.2 Gen 2 Type-A port (red) 2 x USB 3.2 Gen 1 ports 4 x USB 2.0/1.1 ports 1 x Q-Flash Plus button 1 x RJ-45 port 3 x audio jacks |
| H/W Monitoring | Voltage detection Temperature detection Fan speed detection Water cooling flow rate detection Fan fail warning Fan speed control |
| Operating System | Support for Windows 11 64-bit Support for Windows 10 64-bit |
| Form Factor | Micro ATX Form Factor (24.4cm x 24.4cm) |
