MONTECH BETA 550 BRONZE

Product Name
- BETA 550

ATX Version
- ATX12V

PFC
- Active PFC (>0.9 typical)

Input Voltage
- 100-240Vac

Input Current
- 8A

Input Frequency
- 47-63Hz

Dimensions (L*B*H)
- 140*150*86mm

Fan Size
- 120mm

Hold Up Time
- 10msec (minimum) at 80% of full load at 230Vac input.

Efficiency
- 83% Typically

MTBF
- >100,000 Hours

Operating Temperature
- 0-45°C

Protections
- OVP / OPP / UVP / SCP

Regulatory
- cTUVus / TUV / CB / CE / CCC / RoHS / FCC

Connectors
M/B 20+4Pin
- 1
CPU 4+4Pin
- 1
PCIE 6+2
- 2
SATA
- 6
Molex 4Pin
- 2

AC Input
- 100-240Vac 47-63Hz 8.0A

DC Output
- +3.3V
- +5V
- 12V
- -12V
- +5VSB

Max. Output Current
- 18A
- 16A
- 42A
- 0.3A
- 2.5A

Max. Output Power
- 110W
- 504W
- 3.6W
- 12.5W

Total POWER
- 550W
