MSI B650 GAMING PLUS WIFI - 1 - Nano Komputer

MSI B650 GAMING PLUS WIFI

Rp 2.949.000

Brand: MSI

SKU: 824142324080

Estimasi Berat: 1.7 kg

Category: Motherboard

Sub Category: for AMD Processor

AMD B650 Chipset, 4x DDR5 DIMM, Maximum Memory 192GB, Total 5 Slot NVMe, WiFi 6E, Bluetooth 5.4, Support Desktop Processors Socket Intel LGA 1851, ATX Form Factor

4 left
Product description



Chipset AMD B650
CPU Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processors Socket AM5
Memory (DDR5)
  1. 4x DDR5, Maximum Memory Capacity 256GB
  2. Memory Speed Support: DDR5 7200+(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz
  3. Max overclocking frequency:
    • 1) 1DPC 1R Max speed up to 7200+ MHz
    • 2) 1DPC 2R Max speed up to 6000+ MHz
    • 3) 2DPC 1R Max speed up to 6000+ MHz
    • 4) 2DPC 2R Max speed up to 5400+ MHz
  4. Supports Dual-Channel mode
  5. Supports non-ECC, un-buffered memory
  6. Supports AMD EXPO
Onboard Graphics
  1. 1x HDMI™ (Supports HDMI™ 2.1 with HDR, maximum resolution of 4K 60Hz*)
  2. 1x DisplayPort (Supports DP1.4, maximum resolution of 4K 60Hz*)

*Available only on processors featuring integrated graphics.

Expansion Slots
  1. 2x PCI-E x16 slot (PCI_E1 Gen PCIe 4.0 x16 (From CPU), PCI_E3 Gen PCIe 4.0 x4 (From Chipset))
  2. 1x PCI-E x1 slot (PCI_E2 Gen PCIe 3.0 x1 (From Chipset))
Audio Realtek® ALC897 Codec, 7.1-Channel High Definition Audio
Storage
  1. 2x M.2 (M.2_1 & M.2_2 from CPU, supports up to PCIe 4.0 x4)
  2. 4x SATA 6G
Multi-GPU AMD MULTI-GPU Support
RAID
  1. Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices
  2. Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
USB
  1. Front Ports (Internal IO): 4x USB 2.0, 2x USB 5Gbps Type A, 1x USB 10Gbps Type C
  2. Rear Ports (Back Panel): 4x USB 5Gbps Type A, 3x USB 10Gbps Type A, 1x USB 20Gbps Type C
LAN Realtek® 8125BG 2.5G LAN
Wireless & Bluetooth Wi-Fi 6E (Module pre-installed), Supports Bluetooth® 5.3
LED Feature 4x EZ Debug LED
Operating System Supports Windows® 11 64-bit, Windows® 10 64-bit
Form Factor (PCB) ATX, 243.84mm x 304.8mm
Warranty

Limited 3 Years by AAA

Product Info

Nano Komputer

.

Produk resmi dan original

.
