PCCOOLER RZ820

Specifications :

Model No
- RZ820 BK
- RZ820 WH

P/N
- RZ820-BKNWNX-GL (Black)
- RZ820-WHNWNX-GL (White)

CPU Socket
- Intel LGA1851/1700/1200/115X/20XX
- AMD AM4/AM5

Product dimension
- 161×150×165mm(L×W×H)

Color
- Black
- White

Heatpipe
- Φ6mm×4pcs+Φ8mm×4pcs

Middle Fan Dimension
- 140×140×30mm

Middle Fan Speed
- 400~1500±10%RPM

Middle Fan Air Flow
- 71.9CFM

Middle Fan Air Pressure
- 2.12mmH2O

Middle Fan Noise
- 27.1dBA

Middle Fan Rated Voltage
- 12VDC

Middle Fan Rated Current
- 0.1A

Middle Fan Power Consumption
- 1.2W

Front Fan Dimension
- 150×120×25mm

Front Fan Speed
- 500~2200±10%RPM

Front Fan Air Flow
- 86.7CFM

Front Fan Air Pressure
- 3.2mmH2O

Front Fan Noise
- 32dBA

Front Fan Rated Voltage
- 12VDC

Front Fan Rated Current
- 0.2A

Front Fan Power Consumption
- 2.4W

Fan Bearing Type
- FDB

Fan Connector
- 4-Pin PWM

LED Type
- ARGB

LED Connector
- 5V 3Pin

LED Rated Voltage
- DC 5V

LED Rated Current
- ≤0.30A

LED Power Consumption
- ≤1.5W
